9
Temperature Display
Ambient Temperature identified by the degrees and C (or F)
icons (Fig. 4a) is displayed while in the Surface Mode and can be
viewed as part of an Alternate Display when the A (Advance/Left)
button is pressed while in NORM Dive mode.
NOTE: The Informational Displays are described in
detail as the various operating modes they appear
in are presented throughout this manual.
AUDIBLE ALARM
A single short beep is emitted after the Diagnostic check. When
most warning situations activate the Alarm, the unit will emit 1 beep per second for 10 seconds, or
less if the situation is corrected, or it is acknowledged by pressing the A (Advance/Left) button for
2 seconds. If acknowledged by the diver and the situation corrected, the Alarm will sound again
upon reentry into the warning situation, or entry into another type of warning situation.
Warning situations that will sound the Alarm, if ON -
• NORM or NAV Max Depth > Alarm Set Point (user set).
• NORM PO2 > Alarm Set Point (user set).
• NORM Elapsed Dive Time > Alarm Set Point (user set).
• NORM Ascent Rate exceeds 18 MPM (60 FPM) if > 18 M (60 FT) or 9 MPM (30 FPM) if =<
18 M (60 FT) when Ascent Scale is set for Standard.
• NORM Ascent Rate exceeds 18.5 MPM (60 FPM) if > 18 M (60 FT) when Ascent Scale is set
for Navy.
• NAV Serial Number (Leg) Count Down Timers reach :00:03 (:min:sec)
Fig. 4 - TEMPERATURE
a
