41
Fig. 44 -DEPTH ALARM
Fig. 46 -ASCENT RATE ALARM
Fig. 45 -EDT ALARM
NORM DIVE DEPTH ALARM
When Depth exceeds the Alarm value set (a SET 1 selection), the
Audible Alarm will sound, unless set OFF (a SET 2 selection), and
the Current Depth digits will flash (Fig. 44) until Ascent is made
above the Alarm Depth.
> Press the A (Advance/Left) button for 2 seconds to acknowl-
edge/silence the Audible Alarm.
NORM DIVE EDT (Elapsed Dive Time) ALARM
When EDT exceeds the Alarm value set (a SET 1 selection), the
Audible Alarm will sound, unless set OFF (a SET 2 selection), and
the EDT digits will flash (Fig. 45).
> Press the A (Advance/Left) button for 2 seconds to acknowl-
edge/silence the Audible Alarm.
> Flashing will stop when the Audible is silenced.
NORM DIVE ASCENT RATE ALARM
When the Ascent Scale is set for Navy and Ascent Rate exceeds
18,5 MPM (60 FPM) or when the Ascent Scale is set for Standard
and Ascent Rate exceeds 18 MPM (60 FPM) at Depths of 18 M
(60 FT) and deeper or it exceeds 9 MPM (30 FPM) at Depths shal-
lower than 18 M (60 FT), the Audible Alarm will sound, unless set
OFF (a SET 2 selection) and the FULL Ascent Bar Graph will
flash (Fig. 46) until Ascent Rate is slowed below the Alarm value.
> Press the A (Advance/Left) button for 2 seconds to acknowl-
edge/silence the Audible Alarm.
