19
SET MENU
The Set Menu consists of a Sequence containing 3 Set groups followed by a Serial Number screen
then an Ascent Scale Preview screen accessed from the Surface Main screen.
Set Menu Sequence:
NORM SURF MAIN >> SET NAV >> SET 1 >> SET 2 >> SN >> ASC
• SET NAV allows changing of several of the NORM SET functions without accessing those
that do not apply to NAV Mode. It also allows NAV Backlight Mode to be set.
• NORM SET 1 groups settings that would change more often and NORM SET 2 groups those
items not likely to change once they are initially set.
• DIP SN is a view only screen in the Sequence that displays the d.i.P's Serial Number and Firm-
ware Revision number.
• ASC is a view only screen in the Sequence that displays the Ascent Scale selected by PC.
> Access to the Sequence and SET NAV screen (first in Sequence) is gained by simultaneously
pressing Both buttons for 2 seconds. Subsequent 2 second presses of Both buttons are then
used to step through the other Set Mode screens.
> After gaining access to the Set Mode Group desired, settings can be made in sequence one af-
ter the other, or items not to be set can be bypassed.
• Access is gained to Selections in the Set Modes by releasing the buttons during the 2 second
window during which the SET Mode screen is displayed, then pressing the A (Advance/Left)
button.
• If Both buttons are held longer than 2 seconds, that Set Mode or screen will be bypassed.
• While in the Set Mode menu, if neither button is pressed during a period of 2 minutes, opera-
tion will revert to the NORM SURF MAIN screen.
