FINAL CHECKS AND MAINTENANCE
Before the automated system is nally put into operation, and during maintenance work, perform the following checks
meticulously:
- Ax a door/gate identication plate, also ax a warning sign on the frame�
- Make sure that, during operation, mechanical risks are avoided or relevant protective measures taken and, more
specically, that nothing can be banged, crushed, caught or cut between the part being operated and surrounding
parts�
- Make sure the motor automation settings are correct and that the safety and release systems are working properly�
- Make sure all components are fastened securely;
- Check starting and stopping operations in the case of manual control;
- Check that the rack and pinion mesh correctly with 2 mm of play along the entire rack; keep the track the gate slides
on clean and free of debris at all times�
- Make sure all safety devices are in good working order (photocells, sensitive edges, etc�) and that safety devices are
correctly adjusted�
- Impact forces can be reduced by using deformable edges�
- Make sure that the emergency operation works, where this feature is provided�
- Check opening and closing operations with the control devices applied�
- Check that electrical connections and cabling are intact, making extra sure that insulating sheaths and cable glands
are undamaged�
- While performing maintenance, clean the photocells' optics�
- When the automated system is out of service for any length of time, activate the emergency release so that the op-
erated part is made idle, thus allowing the gate to be opened and closed manually�
- The maintenance described above must be repeated at least once yearly or at shorter intervals where site or install-
ation conditions make this necessary�
GATE MOVEMENTS
Gate status
Radio START
button
or
START input
Radio
PEDESTRIAN
button
OPEN input
Opening limit
switch trigger
Closing limit
switch trigger
STOP input Photocell trigger
Amperostop
trigger
(*)
Semi-automatic logic (TCA = O) - 4 steps
Closed Totally opens
If the gate is
closed (closing
limit switch) it
partially opens,
or fully opens
Totally opens No eect No eect
Inhibits
movement
Inhibits opening
No eect
During
opening
Stops opening Stops opening No eect Stops opening No eect
Inhibits
movement
Stops opening to
clearance
Stops and
movement
is reversed
for 1s
Open Closes Closes No eect No eect No eect
Inhibits
movement
Inhibits closing No eect
During
closing
Stops closing Stops closing
Stops closing
and reverses
movement�
No eect Stops closing
Inhibits
movement
Stops closing and
reverses movement
after clearance
Stops and
movement
is reversed
for 1s
Automatic logic (TCA = On) - 4 steps
Closed Totally opens
If the gate is
closed (closing
limit switch) it
partially opens,
or fully opens
Totally opens No eect No eect
Inhibits
movement
Inhibits opening
No eect
During
opening
Stops opening
and closes after
TCA
Stops opening
and closes after
TCA
No eect
Stops opening
and closes after
TCA
No eect
Inhibits
movement
Stops opening to
clearance
Stops and
movement
is reversed
for 1s
Open Closes Closes No eect No eect No eect
Inhibits
movement
Inhibits opening No eect
During
closing
Stops closing Stops closing
Stops closing
and reverses
movement�
No eect Stops closing
Inhibits
movement
Stops closing and
reverses movement
after clearance
Stops and
movement
is reversed
for 1s
(*) If the motor nds a xed obstacle, it runs the clearance manoeuvre�
