Pos. Description Q.ty
1 Sensor assembly 1
2 Motor support flange 1
3 Spacer 4
4 Washer 4
5 Motor gasket 1
6 Motor HS200-2231-0300-AH0 4 1
7 HSHC screw UNI5931- M4x10 4
8 HSHC screw UNI5931- M6x20 4
9 Screw pz type M3x10 UNI 7687 7
10 Control/drive card assembly 1
11 Power supply card 150w max 1
35
© Copyright by BIFFI Italia. All rights reserved.
A !@#$ INTERNATIONAL LTD. COMPANY
F02 Quarter-turn Electric Actuators
instruction and operating manual
DRIVE AND CONTROL UNIT
