Operating the ICON3000
Section 5: Operating the ICON3000
Figure 49 Potentiometer card
Potentiometer card
This card can be used for some special FW versions of the ICON3000.
Figure 50
5.10 Absolute Encoder of the ICON3000
The ICON3000 absolute encoder can measure up to 8,000 output turns. The absolute
encoder maintains the actuator/valve position without electrical power and battery back-up.
Figure 51 Potentiometer card
