Section 6: Local Controls
Local Controls
Table 9. List
The data with * are only present if the relevant modules are present.
2. 3-position selector to set the following operation modes:
• LOCAL: for local control only
• OFF: no control is active but the actuator is still connected to the mains
• REMOTE: for remote control only
3. The ICON3000 can be provided with a radio-frequency wireless connection based
on a qualied Bluetooth class 1 module. This allows exchange of data with a PDA
or PC with built-in Bluetooth™ technology. The following tasks can be wirelessly
performed:
• View and change conguration
• Set maintenance function
• Read maintenance data
• Download new rmware to the ICON3000
• The blue LED indicates that communication with a host device is established
4. Numeric display to indicate the present valve position as a % of open position.
Display resolution is a function of the number of complete turns of the actuator
output shaft:
• From 2 to 4 turns = 0.2%
• From 4 to 8,000 turns = 0.1%
5. Three LEDs to indicate the actuator status according to the following logic:
• green ON/ red OFF: the actuator is stopped in the open position
• green OFF/ red ON: the actuator is stopped in the closed position
• green OFF/ red ashing: the actuator is running in the closing direction
• green ashing/ red OFF: the actuator is running in the opening direction
• green ON/ red ON: the actuator is stopped in an intermediate position
• yellow ON: alarm
• yellow ashing: warning
The above color combination is supplied as standard, but it may be changed
(red to green, green to red, and yellow to red), during actuator setup operations.
output torque mot temp
motor speed term temp
main voltage log status
current wireless report
temperature node report *
time FDI report *
date base report
alarm term report
warning Ain/Aout report *
Ktemp
