Installation, Operation and Maintenance Manual
September 2019
MAN720_IMVS2000v2_IOM Rev. 6
Section 6: Conguration Parameters
Conguration Parameters
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
PST Ser. SOVs
(PST Series SOVs)
It is applicable only if “Act. Mode” ≠ “Double” and
“Pr. S. 1-2” ≠ “None” and “SOVs Qty” ≠ “Parallel."
It determines the way to perform the PST for 2
SOVs in series or to enable the SOVs TEST.
See Sections 5.1.9 and 5.1.6 for details.
One, Both Both R/W
Local, Serial,
Bus
PST. Cyc. L.
(PST Cycle Limit)
It defines the threshold for the generation PSCL
alarm. See Section 8 for details.
1 -100000 10000 R/W
Local, Serial,
Bus
PST Cyc. C.
(PST Cycle Count)
It is a counter of the PST. It is increased by 1 each
time that a PST is performed. It can be reset.
0-100000 0 R/W
Local, Serial,
Bus
PST Ab. C.
(PST Absolute Count)
It is a counter of the PST. It is increased by 1 each
time that a PST is performed. It cannot be reset.
0-1000000 0 R
Local,
Serial,Bus
A. PST En.
(Automatic PST Enable)
It enables the Automatic PST. The Automatic PST is
executed according to the settings of the
parameters “Auto. PST Period” and “Auto. PST
Time." The Automatic PST starts its
periodically execution only if a “Baseline PST” is
already performed.
Yes, No No R/W
Local, Serial,
Bus
A.PST Per.
(Automatic PST Period)
It denes how often the Automatic PST will
automatically run.
1 – 365 days 90 days R/W
Local, Serial,
Bus
A. PST Date
(Automatic PST Date)
It defines the date when the Automatic PST
will start.
01-01-2014
31-12-2099
01-01-
2014
R/W
Local, Serial,
Bus
A.PST Time
(Automatic PST Time)
It defines the hour of the day when the Automatic
PST will be run.
00.00 – 23.59 08.00 R/W
Local, Serial,
Bus
Calibration Cmd
It is the command for performing the device
Calibration. See Section 5.1.1 for details.
The ”Calibration” deletes all the stored Baseline and
Maintenance FSTs and all the stored Baseline and
Manual PSTs.
Start C
Local, Serial,
Bus
Cal. Date
(Calibration Date)
It is the date of the last performed Calibration.
01-01-2014
31-12-2099
01-01-
2014
R
Local, Serial,
Bus
Cal. Time
(Calibration Time)
It is the time of the last performed Calibration. 0.00 – 23.59 08.00 R
Local, Serial,
Bus
Cal. Status
(Calibration Status)
It is the status of the last performed Calibration.
“Not Done”: no Calibration is performed yet.
“Progress”: during the execution of the Calibration.
“Failed”: some errors occur during the last
Calibration. “Passed”: Calibration successfully
performed.
Passed,
Failed,
Progress,
Not Done.
Not Done R
Local, Serial,
Bus
Cal. Enabled
(Calibration Enabled)
If it is set as “Yes” it is possible to perform command
“Calibration” otherwise it does not work.
Yes, No Yes R/W
Local, Serial,
Bus
Base. Sig. Cmd
(Baseline Signature
Command
It is the command for performing the “Baseline
Signature.” See Section 5.1.2 for details.
This command can be performed only if a
Calibration is already successfully performed
(“Cal. Status” = “Passed”) and if the CAL alarm is not
active (see Section 8 for details).
The ”Baseline Signature” deletes all the stored
Maintenance FSTs and Baseline and Manual PSTs
and SOVs Test.
Start C
Local, Serial,
Bus
Mnt. Sig. Cmd
(Maintenance Signature
Command)
It is the command for performing the “Maintenance
Signature." See Section 5.1.2 for details.
This command can be performed only if a Baseline
Signature is already successfully performed
(“Base S. Status” = “Passed”) and if the CAL alarm is
not active (see Section 8 for details).
Start C
Local, Serial,
Bus
Op. Cal. T.
(Opening Calculated
Time)
It is the calculated time for the Opening FST graphs.
See Section 5.2.8 for details.
1.7–2000 sec R
Local, Serial,
Bus
43
