Section 6: Conguration Parameters
Conguration Parameters
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
FST Info
The FST Type, FST Source, FST Status, FST date and
time, FST Break and Travel Times, FST Break Pres-
sure of the selected FST (“FST ID”) are shown.
If “FST ID” > “FST Stored” than “all zeros” are
shown. Using the Serial Interfaces, the “FST Info” is
“included” into the graph of Event (see [1]).
FST Type: “OP” (Opening FST) or “CL” (Closing
FST).
FST Source: “Base” (Baseline Sign.),
“Maint” (Maintenance Sign.),
“D.I.” (Digital Input) or “Ext.”
(External Source).
FST Status: “Not Done,” “Passed,” “Failed,”
“Conf. Err.” See Section 5 for details.
- - R
Local, Serial,
Bus
B. Op. B. T.
(Baseline Opening
Break time)
It is the time measured during the Baseline
Signature (Opening FST) that occurred for go-
ing from the Starting Closed position to the
“Cl. Break Pos." See Section 5.1.8 for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
M. Op. B. T.
(Maintenance Opening
Break Time)
It is the time measured during the last required
Opening FST that occurred for going from the
Starting Closed position to the “Cl. Break. Pos.”
See Section 5.1.8 for details.
It is not updated in case of External Source FST
and Digital Input FST with “M. FST Alr En.”
= “No”. See Section 5.2.8 for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
B. Op. T. T.
(Baseline Opening
Travel Time)
It is the time measured during the Baseline
Signature (Opening FST) that occurred for go-
ing from the “Cl. Break Pos” to the 100% -
“Op.Break Pos.” See Section 5.1.8 for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
M. Op. T. T.
(Maintenance Opening
Travel Time)
It is the time measured during the last required
Opening FST that occurred for going from the
“Cl. Break Pos” to the 100% - “Op.Break Pos.”
See Section 5.1.8 for details.
It is not updated in case of External Source FST
and Digital Input FST with “M. FST Alr En.”
= “No”. See Section 5.2.8 for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
B. Op. B. P.
(Baseline Opening
Break Pressure)
It is the pressure measured during the Baseline
Signature (Opening FST) when the position
reaches “Cl.Break Pos.”
See Section 5.1.8 for details.
If “Act. Mode” ≠ “Single”, this pressure value is
made by the absolute value of the difference
between Pressure 1 and Pressure 2
0 – 400 bar
(0 – 5800 psi)
0 bar R
Local, Serial,
Bus
M. Op. B. P.
(Maintenance Opening
Break Pressure)
It is the pressure measured during last required
Opening FST when the position reaches “Cl.
Break Pos.” See Section 5.1.8 for details.
If “Act. Mode” ≠ “Single”, this pressure value is
made by the absolute value of the difference
between Pressure 1 and Pressure 2.
It is not updated in case of External Source FST
and Digital Input FST with “M. FST Alr En.”
= “No." See Section 5.2.8 for details.
0 – 400 bar
(0 – 5800 psi) 0 bar R
Local, Serial,
Bus
