Section 6: Conguration Parameters
Conguration Parameters
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
Cl. Status
(Closing Status)
It is the status of the last closing FST.
It is “Not Done” if no Closing FST is performed
yet. It is “Failed” if at least one of the following
alarms is generated during the execution of the
last Closing FST: SCBT, FCBT, SCTT, FCTT, CHBP,
CLBP CLNM and CLCT. Otherwise it is “Passed.”
See 8 for details.
It is set to “Not Done” after every Calibration or
Baseline Sign.
Not Done,
Passed,
Failed.
Not Done R
Local, Serial,
Bus
Mnt S. St.
(Maintenance
Signature Status)
It is the status of the last Maintenance Signa-
ture. “Not Done”: no Maintenance Signature is
performed yet.
“Progress”: during the execution of a Mainte-
nance Signature. “Failed”: if at least one of the
following alarms is generated during its last
execution: SOBT, FOBT, SOTT, FOTT, OHBP,
OLBP, SCBT, FCBT, SCTT, FCTT, CHBP, CLBP,
CLCT, CLNM, OPNM and OPCT.
“Conf_Err”: the command is not performed
due to wrong conguration or “Pos. Req” not
aligned with “Position” or if the command is not
available (“Signatures En.” or “Base. S. Status”),
or “Op. Max time” = 0 or “Cl. Max Time” = 0,
CAL or POS alarms active, etc.
Otherwise it is “Passed."
“Failed” is squelched by “Conf. Err.”
See 8 for details.
It is set to “Not Done” after every Calibration or
Baseline Sign.
Not Done,
Passed,
Failed, Prog-
ress
Conf_Err
Not Done R
Local, Serial,
Bus
M.S. Date
(Maintenance
Signature Time)
It is the date of the last performed Maintenance
Signature.
It is set to “01-01-2014” after every Calibration
or Baseline Sign.
01-01-2014
31-12-2099
01-01-
2014
R
Local, Serial,
Bus
M.S. Date
(Maintenance
Signature Time)
It is the time of the last performed Maintenance
Signature.
It is set to “08.00” after every Calibration or
Baseline Sign.
00.00 – 23.59 08.00
R
Local, Serial,
Bus
FST Stored
It indicates the number of the stored FSTs.
It is set to “0” after every Calibration.
It is set to “2” after every Baseline Signature
successfully done.
0-50 0 R
Local, Serial,
Bus
FST ID
It indicates the FST whose data are shown in the
“FST Info.”
The FST ID 1 and 2 are dedicated to the FSTs of
the Baseline Signature.
The last FST (not one of the Baseline Signature)
has the”FST ID” = 3 and the oldest FST has the
“FST ID” = “FST Stored.”
1-50 0 R/W
Local, Serial,
Bus
