Section 6: Conguration Parameters
Conguration Parameters
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
Pres. M.U.
(Pressure Measurement
Unit)
It denes the measure unit of the pressure.
After changing its value the pressures of the
“Normal Mode Menu” is immediately aligned to
the new setting.
The pressure of the graphs (Signatures, FST
and PST) is stored according to value of this
parameter.
The setting of this parameter must be done
before starting the commissioning procedure
otherwise it is necessary to perform a new
commissioning procedure after changing this
parameter.
See Section 10.7 for details.
bar, psi bar R/W
Local, Serial,
Bus
CFA Mode
(Common Failure
Alarm Mode)
It denes the way of work of the “ALARM”
digital output.
“NC” = normally closed
“NO” = normally open
See Section 5.2.3 for details.
NO, NC NO R/W
Local, Serial,
Bus
Op. Cl. Mode
(Open Close DO Mode)
It denes the way of work of the “OPEN” and
“CLOSED” digital outputs.
“NC” = normally closed
“NO” = normally open
See Section 5.2.3 for details.
NO, NC NO R/W
Local, Serial,
Bus
Bus Type
If a bus card is present, it species the type.
“None” = no bus card present.
None, HART,
MOD.
NONE R/W
Local, Serial,
Bus
Blue. En.
(Bluetooth Enabled)
If set as “Yes” the Bluetooth Interface is
enabled.
Yes, No. Yes R/W Local.
Change User PWD
(Change User Password)
It is the Password of the Local Operator
Interface for logging in as “User”.
It is possible to set the new value when logged
in as “User”.
The new password is active (the old one is no
longer valid) after the log out.
8 characters 00000000 R/W Local
“M. FST Al. En.”
(Manual FST Alarm
Enabled)
If set as “Yes” the manual FST (through Digital
Input or RL A CMD or RL B CMD) causes the
updating of the “FST Run Times” parameters
and the possible activation of the alarms
related to the FST execution (see 5.2.7 and 8
for details).
If set as “No” the manual FST (through Hard
Wired Commands) does not cause the updating
of the “FST Run Times” parameters and the
alarms related to the FST execution cannot be
activated (see Sections 5.2.7 and 8 for details).
In any case the FST graph is stored.
Yes, No. Yes R/W
Local, Serial,
Bus
DI_SOVA St.
(DI_SOVA Status)
It indicates the presence of voltage on the
SOLENOID A CONTROL digital input.
“High” = Voltage applied.
“Low” = Voltage not applied.
See Sections 5.2.2 and 9.1for details.
High, Low R
Local, Serial,
Bus
DI_SOVB St.
(DI_SOVB Status)
It indicates the presence of voltage on the
SOLENOID B CONTROL digital input.
“High” = Voltage applied.
“Low” = Voltage not applied.
See Sections 5.2.2 and 9.1for details.
High, Low R
Local, Serial,
Bus
