Bilancial D410 - Technical Specifications

1.6 Technical characteristics of the terminal
Power supply
85-265 Vac 50/60 Hz
12-24 Vdc (optional)
Maximum power: 50 W
Load cell connection:
up to 12 analogue load cells of
350 ohm via 9-pin D-type
connector
up to 12 CPD digital load cells via
15-pin D-type connector
Minimum impedance: 29 ohm
10 VdcAnalogue load cell power:
10 - 18 VdcDigital load cell power:
Internal resolution:
500000 points @ 25 conv/sec
120000 points @ 100 conv/sec
10000 divisions maximumResolution in type-approved
version:
23 mVMaximum input signal:
Sensitivity: 0.75 uV/division (version with
analogue load cells)
Full scale stability:
< 5 ppm/°C
Zero stability:
< 5 ppm/°C
-10 + 40 °CCompensated temperature range:
-10 + 50 °COperating temperature range:
Protection class: IP20
85 % @ 40°C
Humidity:
D410
1-10
