Bilancial D410 - Calculator BCD

6.3 Calculator BCD
A label next to the connector identifies the type of board.
The 25-pin female connector provides the following BCD signals
representing the weight in divisions without taking into account the value
of the division.
CAUTION
The operating limits for this type of output are:
V out Max = +5V
I out Max = +/- 10 mA
D410
1-63
