CAUTION
Technical characteristics:
Resolution= 10000 points
Precision = 0.05 % FS
Minimum voltage output load = 100 kohm
Minimum current output load = 250 ohm
3.6 Input/Output connection
The terminal board JI/O on the rear of the instrument (point 6 Figure 3.1
on page 1-17 ) provides input and output contacts; Figure 3.8 on page
1-27 contains the pinout diagram.
Key
Pi = Part inside terminal
Pe = Part outside terminal
Figure 3.8 - JI/O terminal board for Input/Output connections
(log0008.gif)
D410
1-27
