CAUTION
Operating limits stipulated by the standard RS485:
Maximum transmission distance = 1200 m
Maximum line voltage = +/- 7V
For connection to external devices, use a screened twisted
pair cable and connect the screen to the metal cap of the
9-pin connector.
Maximum number of terminals that may be connected = 16
3.5 Analogue output connection
The connector JVI located on the rear of the terminal (point 5 Figure 3.1
on page 1-17 ) provides an analogue output in the forms 0-10 V and
0(4)-20 mA galvanically separated; the connection pinout is given in the
following table.
Pin n°
Signal
1
Output 0-10 V
2
Output 0(4)-20 mA
3
Common
D410
1-26
