6.4 Parallel 24V source current BCD (positive common)
A label next to the connector identifies the type of board.
The 25-pin female connector provides the following BCD signals
representing the weight value as it is displayed on the terminal, i.e. the
number of divisions multiplied by the value of the division.
CAUTION
The operating limits for this output type are as follows:
V out Max = +24V
I out Max = + 10 mA
D410
1-65
