Listed below are the weighing symbols displayed and their meanings:
Weight stable symbol
Indicates that the weight value displayed is stable
and thus may be printed and/or transmitted.
Centre zero symbol
Indicates that the weight on the scale is near to
zero i.e. within -1/4 + 1/4 of a division.
Tare symbol
Indicates the presence in memory of an acquired
tare value.
Preset tare symbol
Indicates that a tare value has been entered from
the keypad.
Gross weight symbol
Gross weight symbol with units of
measurement in lb (as alternative to B)
This symbol only illuminates when the unit of
measurement is "lb" (pounds).
Minimum weighment
Net weight symbol
Weighing range indication for multi-extension
(ME) instruments
4.1.1 Selection display symbols
Weight indication
Below preset lower limit.
D410
1-30
