6. OPTIONS
Optional expansion boards (with the exception of the MPP memory
expansion board) are installed in the slots provided on the rear of the
terminal (see points 11,12 Figure 3.1 on page 1-17 ).
For the positions and numbering of the outputs (I/O, COM, BCD), refer
to the label on the bottom of the terminal.
Figure 6.1 - Outputs identification label on base of terminal
(log0125.jpg)
The numbering of the I/O points, the serial ports and the BCD ports is to
be considered along with the position of the boards in the slots (see
Figure 3.1 on page 1-17 ).
D410
1-57
