1.4 Type plate
The type plate is located on the left-hand side of the unit (size 23) or on the unit front behind the door,
bottom left-hand.
Figure 2: Type plate (example: FD 115 regular unit)
Indications of the type plate Information
Nominal temperature 300 °C
572°F
Nominal temperature
Enclosure protection IP 20 IP type of protection 20 acc. to EN 60529
Temp. safety device DIN 12880 Temperature safety device acc. to standard DIN 12880
Class 2.0 Temperature safety device, class 2
Art. No. 9010-0102 Art. No. 9010-0102
Project No. --- (Special application acc. to project no.)
1,60 kW Nominal power 1.60 kW
230 V 1 N ~
Nominal voltage 230 V ± 10%, single-phase unit
7,0 A Nominal current 7.0 Amp
50/60 Hz Power frequency 50/60 Hz
FD 115 Model FD 115
Serial No. 00-00000 Serial No. 00-00000
Symbol on the type plate Information
CE conformity marking
Electrical and electronic equipment manufactured / placed on
the market in the EC after 13 August 2005 and to be disposed
of in a separate collection according to directive 2002/96/EC
on waste electrical and electronic equipment (WEEE).
VDE-GS certification mark
The equipment is certified in the GOST R certification system
of GOSTSTANDARD Russia.
LABORATORY EQUIPMENT
43KM
(UL units only)
The equipment is certified by Underwriters Laboratories Inc.
®
according to standards UL 61010A-1, UL 61010A-2-10, CSA
C22.2 No. 1010.1-92, and CSA C22.2 No. 1010.2.010-94.
Nominal temperature 300 °C 1,60 kW
572°F 230 V 1 N ~
Enclosure protection
Temp. safety device
IP 20
DIN 12880
7,0 A
50/60 Hz
Class 2.0
Art. No. 9020-0102 US PATS 5405194 / 5222612
Project No. US PATS 4585923 / 5309981
D 78532 Tuttlingen / Germany
Tel. + 49 (0) 7462/ 2005-0
Internet: www.binder-world.com
FD 115 Serial No. 00-00000
Made in Germany
