12.3 Over current protection
Single-phase devices are protected by a miniature fuse against over current, accessible from the
outside. The miniature fuse is located at the rear of the chamber below the strain relief of the power cord.
The fuse holder is equipped with a fuse clip 5mm x 20 mm. (CUL-Version 6,3x32 mm). The fuse may be
replaced only with a substitute of the same ratings. Refer to the technical data of the respective device
type.
Three-phase devices are equipped with internal fuses not accessible from outside. If these fuses are
blown, please inform an electronic engineer or BINDER service.
12.4 BD technical data
Unit size BD 23 BD 53 BD 115 BD 240 BD 400 BD 720
Exterior dimensions
Width mm
inch
435
17.13
635
25.00
835
32.87
1035
40.75
1235
48.62
1235
48.62
Height (incl. feet/castors) mm
inch
495
19.49
620
24.41
705
27.76
825
32.48
1025
40.35
1530
60.24
Depth mm
inch
520
20.47
575
22.64
645
25.39
745
29.33
765
30.12
865
34.06
incl. door handle and exhaust duct mm
inch
105
4.13
105
4.13
105
4.13
105
4.13
105
4.13
105
4.13
Wall clearance rear mm
inch
100
3.94
100
3.94
100
3.94
100
3.94
100
3.94
100
3.94
Wall clearance side mm
inch
100
3.94
160
6.30
160
6.30
160
6.30
160
6.30
160
6.30
Exhaust duct, outer diameter mm
inch
52
2.05
52
2.05
52
2.05
52
2.05
52
2.05
52
2.05
Steam space volume l
cu.ft.
36
1.27
70
2.47
142
5.02
283
10.0
457
16.15
808
28.55
Number of door(s) 1 1 1 2 2 2
Interior dimensions
Width mm
inch
222
8.74
400
15.75
600
23.62
800
31.50
1000
39.37
1000
39.37
Height mm
inch
330
12.99
400
15.75
480
18.90
600
23.62
800
31.50
1200
47.24
Depth mm
inch
277
10.91
330
12.99
400
15.75
500
19.69
500
19.69
600
23.62
Interior volume l
cu.ft.
20
0.7
53
1.9
115
4.1
240
8.6
400
14.3
720
25.7
Quantity of racks (regular / max.) 2/3 2/4 2/5 2/7 2/10 2/15
Load per rack Kg
lbs
12
26
15
33
20
44
30
66
35
77
45
99
Permitted total load Kg
lbs
25
55
40
88
50
110
70
155
90
199
120
265
Weight (empty) Kg
lbs
26
57
43
95
61
135
93
205
135
298
191
422
