Binder APT.line BD 53 - Page 42

BD / ED / FD (E2) 11/2010 page 42/54
Unit size BD 23 BD 53 BD 115 BD 240 BD 400 BD 720
Temperature data
Temperature range, 5 ° C / 9 °F
above ambient up to
°C
°F
100
212
100
212
100
212
100
212
100
212
100
212
at 37 °C ± K 0.5 0.5 0.4 0.5 0.5 0.5 Temperature uniformity
(variation 1)
at 50 °C ± K 1.8 1.1 0.8 0.9 0.9 0.8
at 37 °C ± K 0.2 0.1 0.1 0.1 0.1 0.1 Temperature fluctuation
at 50 °C ± K 0.3 0.1 0.1 0.1 0.1 0.1
to 37 °C Min 49 38 62 70 105 84 Heating up time 2)
to 50 °C Min 51 59 91 115 132 90
at 37 °C Min 3 5 5 5 6 4 Recovery time after door
was opened for 30 sec 2)
at 50 °C Min 4 7 7 6 29 24
Electrical data
IP system of protection acc. to EN
60529
IP 20 20 20 20 20 20
Nominal voltage (±10 %) 50/60 Hz V 230 1N~ 230 1N~ 230 1N~ 230 1N~ 230 1N~ 230 1N~
Nominal power kW 0.2 0.4 0.4 0.68 0.85 1.25
Energy consumption at 37°C / 98.6°F Wh/h 11 11 20 33 56 80
Unit fuse 5 x 20 mm
230V / 10A / middle-time-lag (M)
Amp 10
external
10
external
10
external
10
external
10
external
10
external
Power plug shock proof plug
Installation category acc. to IEC 61010-1 II II II II II II
Pollution degree acc. to IEC 61010-1 2 2 2 2 2 2
Electrical connection data BD-UL acc. to cUL standard (for USA and Canada):
Unit size BD 23-
UL
BD 53-
UL
BD 115-
UL
BD 240-
UL
BD 400-
UL
BD 720-
UL
Electrical data
Nominal voltage (±10%) 60 Hz V 115 1N~ 115 1N~ 115 1N~ 115 1N~ 115 1N~ 115 1N~
Nominal power kW 0.20 0.30 0.40 0.68 0.85 1.25
Nominal current Amp 1.8 2.6 3.5 5.9 7.4 10.9
Power plug NEMA 5-15P 5-15P 5-15P 5-15P 5-15P 5-20P
Unit fuse 6,3 x 32 mm 250V / super-
time-lag TT
Amp 12,5
external
12,5
external
12,5
external
12,5
external
12,5
external
16
external
Additional temperature fuse class 1
(DIN 12880)
internal internal internal internal internal internal
Legend: 1) without outer glass door 2) up to 98 % of the set value
All technical data is specified for units with standard equipment at an ambient temperature of +25 °C / 77
°F and a power supply voltage fluctuation of ±10. The temperature data is determined in accordance to
BINDER factory standard following DIN 12880, observing the recommended wall clearances of 10 % of
the height, width and depth of the inner chamber.
All indications are average values, typical for units produced in series. We reserve the right to
change technical specifications at any time.
If the cabinet is fully loaded, the specified heating up times may vary according to the load.
With option interior socket: If electrical devices are connected and operating inside the
chamber, the temperature range may be modified due to heat emission.
