VD (E3.1) 03/2020 page 158/173
Different electrical data for VD-UL constructed for the USA and Canada
(model versions VD023UL-120V, VD056UL-120V, VD115UL-120V)
Nominal voltage (+/-10%) at 60 Hz power
V 115 115 115
Chamber fuse 5 x 20 mm / 250V / time-lag T
Chamber fuse 6.3 x 32 mm / 250V / time-lag
T
A -- -- 2 x 20
Power plug of pump module (option)
Environment-specific data
Noise level VD (mean value)
Energy consumption
*** Data not yet determined
All technical data is specified for unloaded chambers with standard equipment (with aluminum racks) at
an ambient temperature of +22 °C +/- 3 °C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of
+/- 10 %. Technical data is determined in accordance to BINDER Factory Standard Part 2:2015 and DIN
12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right
to change technical specifications at any time.
26.4 Equipment and options (extract)
To operate the chamber, use only original BINDER accessories or accessories / components
from third-party suppliers authorized by BINDER. The user is responsible for any risk arising
from using unauthorized accessories.
RD4 microprocessor program controller with LED display
Ethernet interface for computer communication
Safety controller (safety device class 2 according to DIN 12880:2007)
Inert gas connection / ambient air inlet “GAS/AIR”, adapter with hose olive 8 mm, with fine-dosing valve
for aeration / inert gas
Measuring connection (DN 16), rear
Expansion racks, aluminum or stainless steel 1.4571
Microprocessor program controller MB2 with touchscreen
Analog outputs 4-20mA for temperature and pressure
Additional inert gas connection / ambient air inlet “GAS/AIR 2”, adapter with hose olive 8 mm, with fine-
dosing valve for aeration / inert gas
Additional universal access port 40 mm / 1.57 in
FKM door gasket (temperature resistant up to 150 °C / 302 °F)
Object temperature display with flexible Pt 100 temperature sensor
