4.2 Pump module (option)
The mounting instructions Art. no. 7001-0137 supplied with the pump module describe
how to mount the VD vacuum drying oven onto the pump module and installing the
suction line into the pump module.
Vorderansicht
Rückansicht
Figure 10: VD mounted on pump module (example: size 115)
Figure 11: Pump module, rear view with connection panel (example: size 115)
(13)
(14)
(15)
(16)
(13)
(14)
