10. Technical data
Supply voltage 1×230 V +6/-10%, 50/60 Hz, PE
Motor protection External motor protection is not required
Type of protection IP 44 (EN 60529)
Winding category Insulation category F
Temperature category TF 110 (EN 60335-2-51)
Media temperature +15°C to +110°C
The temperature of the medium must be higher than the ambient
temperature to prevent condensation water from forming in the terminal
box and the stator.
Ambient temperature Media temperature
°C Min. °C Max. °C
0 2 110
15 15 110
30 30 110
35 35 90
40 40 70
Ambient temperature 0°C to +40°C
Operating pressure Max. 10 bar, 102 m, 1 MPa
Inow pressure
Media-
temperature
Minimunm inow pressure
[bar] [m] [MPa]
≤ +75 °C 0.05 0.5 0.005
+90 °C 0.30 3.0 0.030
+110 °C 1.1 11.0 0.110
Noise Sound pressure level under 43 dB(A)
Electromagnetic compatibility EMV guidelines (2004/108/EC)
Standards: EN55014-1:2006, EN55014-2:1997
EEI-values AX xx-3 = EEI ≤ 0.19
AX xx-4 = EEI ≤ 0.20
AX xx-6 = EEI ≤ 0.23
11. Disposal
This AX... circulation pump was developed with sustainability in mind. This also includes
waste prevention and recyclability of materials. This product as well as its parts must be
disposed of according to the local regulations.
