Installation Instruction manual A400 / A400FB
4 - 8 6.054.98.5.10.06 en
4
Application example
Fig. 18: Application example
The illustration shows how the insertion
plates and the remnant holder can be
used.
WARNING Missing components!
The operator can only be protected from injuries and the machine
protected against damage if all the components of the machine are
assembled properly.
– Check if the machine is complete before it is re-started.
– Check if components are positioned correctly and firmly.
– Only use original Bizerba spare parts and accessories.
4.5.3 Switch off optional, external
This option allows disconnecting specified slicer drives from the drive electronics by
means of a contactor.
From the contactor, two cables are let outward via the base plate of the slicer. (control
contactor, feedback)
A supplement contains the precise connection values of the cables.
