Maintenance Instruction manual A400 / A400FB
8 - 2 6.054.98.5.10.06 en
8
8.2 Removing components
CAUTION Chain, driver and gripper hooks, scraper edge!
Stab and cut wounds.
Twisted guide cogs or chain hooks can cause malfunctions.
– Always wear cut-proof gloves when cleaning.
– Avoid touching the chain hooks.
– Claws are lowered into a rest position.
Do not place parts on top of each other to avoid mechanical damage.
Remove components as follows:
Depositing table A400
Fig. 36: Remove depositing table
Use both hands on the operator side to
lift it up a little and pull to the front.
