Bizerba A400 User Manual

Technical data Instruction manual A400 / A400FB
9 - 2 6.054.98.5.10.06 en
9
A402FB A404FB A406FB
Outer dimensions 850 x 1,710 mm 1050 x 1,710 mm =
41.4" x 67.4"
1255 x 1,710 mm =
49.4" x 67.4"
Height on stand (dis-
play on motor tower)
1,535 mm 1,535 mm = 60.5" 1,535 mm = 60.5"
Height on stand (dis-
play on drive housing)
1,370 mm 1,370 mm = 54" 1,370 mm = 54"
Conveyor belt, appli-
cable length
1,000 mm 1,000 mm = 39.4" 1,000 mm = 39.4"
Conveyor belt, appli-
cable width
250 mm 250 mm = 9.9" 250 mm = 9.9"
Product size, round 50 to 180 mm 50 to 180 mm = 2" x
7.1"
50 to 180 mm = 2" x
7.1"
Product size, rectan-
gle
50 x 50 to 175 x
240 mm
50 x 50 to 175 x 240
mm = 2" x 2" to 6.9" x
9.5"
50 x 50 to 175 x 240
mm = 2" x 2" to 6.9" x
9.5"
Slice thickness set-
ting
0.5 to 12 mm 0.5 to 12 mm = 0.02"
to 0.5"
0.5 to 12 mm = 0.02"
to 0.5"
Number of carriage
strokes
30 to 55
strokes/min
30 to 55 strokes/min 30 to 55 strokes/min
Blade diameter 330 mm 330 mm = 13" 330 mm = 13"
Blade speed 266 rpm 266 rpm 266 rpm
Weight machine 116 kg 116 kg = 256 lbs 116 kg = 256 lbs
Weight, bench 16 kg 16 kg = 36 lbs 16 kg = 36 lbs
9.2 Voltage supply
Technical data of power supply
– Mains supply
Single-phase alternating current, see rating plate
– Permissible mains voltage tolerance (static) normal
At 100 to 400V: +6% to -10% of nominal value
– Mains frequency: 50 (60) Hz
Permissible tolerance of mains frequency: +2% to -2% of nominal value
Admissible distortion factor of mains voltage: smaller equal 5 %
– Leakage current protective conductor max.: 3.5 mA
