Machine and operating elements Instruction manual A400 / A400FB
5 - 6 6.054.98.5.10.06 en
5
Fig. 22: Depositing station
<F1> Stacking
<F2> Fan longitudinally
<F3> Fan lengthwise multi-layer
<F4> Shaving
<F5> Reduce distance between rows
<F6> Distributed depositing
<F7> Double stacking
<F8> Fan transversely
<F9> Fan transversely, multi-layer
<F11> Increase row space
<F12> Back to workstation
The depositing positions "Double stacking" and "Fan multi-layer" are on-
ly possible for table-mounted machines.
5.6 Measuring station
This is where the dimensions for the sliced product are entered.
Select one of the pre-set values via the function keys or enter a size between 50 mm and
180 mm via the numeric keys. This important for correct delivery.
