Operation Instruction manual A400 / A400FB
6 - 2 6.054.98.5.10.06 en
6
Fig. 33: Unlocking product feed
Pull the lever towards the operator while
at the same time pushing the guide
manually up to the stop plate.
Position the Sliced products support
Carriage 600 mm with Sliced product holder:
Fig. 34: Carriage 600 mm, insert product
Position the sliced product with the left
hand against the back panel of the car-
riage and press against the holder and
downwards towards the hooks.
Push the lever downwards with your
right hand; this causes the gripper
hooks to hook into the end of the sliced
product and hold it firm (possibly en-
large the end piece by cutting into it).
Push sliced product towards stop plate.
Position the Sliced products support
Via the function keys of the operating and display panel select and enter required
functions and depositing programs.
<Press slicing start/stop>.
The carriage starts moving, the slices are placed on the depositing table or conveyor
belt based on program settings.
Drive is automatically turned off in the following instances:
– if max. stacking height is reached
– light barrier is reached (only in conveyor machines)
– End of sliced products
– End of program
Once the slicing process is completed set slice thickness to "0".
Switch off machine.
