BK Precision 8500B Series User Manual

Operation Modes 44
6.2.4 Congure Pulse Transient Mode
To congure and run the Pulse Transient operation:
Step 1. Select the desired Static Mode.
Step 2. Press the + buttons to enter the Transient Conguration menu.
Step 3. Use the right and left navigation keys to set TRAN to "ON", then press the to conrm
the selection.
Step 4. Use the right and left navigation keys to set MODE to "PULSE". Press the to conrm
the transient mode.
Steps 5 and 6 only apply if the static mode is set to Constant Current.
Step 5. Use the numeric keypad to set UP. Press the to conrm the current rise time.
Step 6. Use the numeric keypad to set DOWN. Press the to conrm the current fall time.
Step 7. Use the numeric keypad to set LEVEL A. Press the
to conrm the value of level A.
Step 8. Use the numeric keypad to set LEVEL B. Press the to conrm the value of level B.
Step 9. Use the numeric keypad to set WIDTH. Press the to conrm the pulse width of the
transient.
Step 10. Use the right and left navigation keys to set TRAN to "ON", then press the to enable
congured transient.
– Upon pressing
the VFD will display TRAN. below the current reading.
Step 11. Enable the input and provide the required trigger function to start the transient operation.
– The initiation trigger required will vary based on the currently set trigger type. For additional
details on the available trigger types, please refer to section 7.5.
