Operation Modes 55

• Use the numeric keypad to set the LOW value. Press the

to conrm the lower limit

for the program test step.

• Use the numeric keypad to set the UP value. Press the

to conrm the rise time for

the program test step.

• Use the numeric keypad to set the DOWN value. Press the

to conrm the fall time

for the program test step.

• Use the numeric keypad to set input value for the selected static operation mode. Press

the to conrm.

• Press the + to enter the save menu.

– Use the numeric keypad to the step value to whom the congured setup will be assigned

to.

Step 12. Repeat step 11 for all remaining active steps.

6.5.2 Run a Program Test

Once you have congured the program test, proceed to follow the steps below for executing the program

test.

Step 1. Press the + to enter the System menu.

Step 2. Use the navigation keys to select the RUNMODE submenu. Press the to enter the

RUNMODE submenu.

Step 3. Use the navigation keys to select the PROG_TEST mode. Press the to enable the

program test mode.

• Upon enabling the program test mode the instrument will automatically exit the system menu

and load the program test interface.

Step 4. Press the

+ to enter the Recall Program menu.

Step 5. Use the numeric keypad to select the program le that will be executed. Press the to

recall the selected le.

Step 6. Provide the required trigger to execute the program test.

– The initiation trigger required will vary based on the currently set trigger type. For additional

details on the available trigger types, please refer to section 7.5.
