BK Precision 8500B Series User Manual

Operation Modes 53
6.5.1 Program Test Conguration
The 8550B series is capable of storing up to 10 Program Test proles.
To congure a program test le:
Step 1. Press the
+ button to enter the Program Test menu.
Step 2. Use the numeric keypad to activate the desired steps. Press the
to conrm the active
steps.
Pressing , , will enable step 1, 2, and 3 as shown in the gure above.
Step 3. Use the numeric keypad to enable a pause in the selected steps. Press the to conrm
the active steps.
Pressing , , will enable a pause for steps 1, 2, and 3 as shown in the
gure above. Press the down navigation key to resume a paused step.
Step 4. Use the numeric keypad to enable the short circuit function for the selected steps. Press the
to conrm short function for the selected steps.
Pressing activates the short function for step 2. In the visual representation,
inactive steps are denoted by N, active steps with the short function enabled are
indicated by Y, and active steps with the short function disabled will display the
step number, as illustrated in the gure above.
