Operation Modes 60
Step 7. Use the numeric keypad to set the STEP DEL. Press the
to conrm the delay time to
hold each step. This dictates the speed at which the test will progress through each step.
Step 8. Use the numeric keypad to set the power END value. Press the
to conrm the power
value that will terminate the test.
Step 9. Use the numeric keypad to set the OPP VOLT value. Press the to conrm the voltage
stop condition.
This threshold serves as a benchmark for assessing Over Power Protection
(OPP) conditions. Should an overcurrent situation arise with the input voltage
surpassing this threshold, the test will progress incrementally from "Start Power"
to "End Power." Throughout this progression, the input current, representing the
overcurrent, will be scrutinized. If the current falls within the limits dened by
"Max Trip Power" and "Min Trip Power," the system will register a "Pass" at the
conclusion of the test. Conversely, if the power exceeds these boundaries, the
system will register a "Fault."
Step 10. Use the numeric keypad to set the MAX TRIP value. Press the to conrm the acceptable
upper power limit .
Step 11. Use the numeric keypad to set the MIN TRIP value. Press the
to conrm the acceptable
lower power limit .
Step 12. Use the numeric keypad to set the SAVE OPP FILE location. Press the to conrm the
memory location where the congured le will be stored.
• Upon pressing
the instrument will automatically exit the OPP Test Conguration
menu.
