Model 8542B 8500B 8502B 8510B 8514B
Readback voltage
Range
Low 0 to 18 V 0 to 50 V 0 to 18 V
High 0 to 150 V 0 to 500 V 0 to 120 V
Resolution
Low 0.1 mV 1 mV 0.1 mV
High 1 mV 10 mV 1 mV
Accuracy ±(0.05% + 0.05% FS)
Readback current
Range
Low 0 to 3 A 0 to 3 A 0 to 12 A 0 to 24 A
High 0 to 30 A 0 to 15 A 0 to 120 A 0 to 240 A
Resolution
Low 0.1 mA 1 mA
High 1 mA 10 mA
Accuracy ±(0.05% + 0.05% FS)
Readback power
Range 150 W 300 W 300 W 600 W 1500 W
Resolution 10 mW
Accuracy ±(0.1% + 0.1% FS) ±(0.2% + 0.2% FS)
Protection range (typical)
OPP 160 W 320 W 320 W 620 W 1550 W
OCP
Low 3.3 A 3.3 A 13 A 26.7 A
High 33 A 16 A 130 A 267 A
OVP 160 V 530 V 125 V 125 V
OTP 185 °F (85 °C) 203 °F (95 °C) 185 ºF (85 ºC)
Short circuit (typical)
Current (CC)
Low 3.3 A 3.3 A 3.3 A 13 A 26.7 A
High 33 A 33 A 16 A 130 A 267 A
Voltage (CV) 0 V
Resistance (CR) 80 mΩ 40 mΩ 180 mΩ 15 mΩ 8 mΩ
General
Input terminal impedance (typical) 150 kΩ 1 MΩ 150 kΩ
AC input 110 V/220 V ±10%, 50/60 Hz
I/O Interface DB9 (TTL) with TTL to USB serial adapter USB, RS232
Temperature
Operating 32 °F to 104 °F (0 °C to 40 °C)
Storage 14 °F to 140 °F (-10 °C to 60 °C)
Humidity Indoor use, ≤ 95 %
Safety EN 61010-1:2010, Low Voltage Directive (LVD) 2014/35/EU
Electromagnetic compatibility EN61326-1:2013, CISPR 11, EN 61000-3-2:2014, EN61000-3-3:2013, EMC Directive 2014/30/EU
Dimensions (W x H x D) 8.5” x 3.5” x 14” (214.5 x 88.2 x 354.6 mm)
8.5” x 3.5” x 18.5”
(214.5 x 88.2 x 470 mm)
17.2” x 3.5” x 18.5”
(436.5 x 88.2 x 470 mm)
Weight 10.3 lbs (4.7 kg) 15.8 lbs (7.2 kg) 45 lbs (20.5 kg)
Warranty 3 years
Standard accessories
Power cord, USB cable, certificate of calibration, USB to TTL serial converter IT-E132B
(3)
, rack-mount ears
(4)
Optional accessories TLPWRI high current test leads, IT-E151 rackmount kit
