LES301A user manual
724-746-5500 | blackbox.com
Chapter 1: Specifications
1.6.4 RUN LED
Table 1-6. RUN LED.
Message Description
LED on Jumper JP1 Pin 1 and Pin 2 are short; this disables AP firmware in flash memory
LED is blinking at the rate once every 0.5 sec AP firmware is running
