Group ID Parameter Type Index Minimum Maximum Interpretation
Display
.3 Peaking level fixed16 – 0 1
0.0=minimum,
1.0=maximum
.4
Color bars display
time (seconds)
int8 – 0 30
0=disable bars,
1-30=enable bars with
timeout (s)
.5 Focus Assist int8
[0] = focus
assist method
– –
0=Peak,
1=Colored lines
[1] = focus
line color
– –
0=Red,
1=Green,
2=Blue,
3=White,
4=Black
Tally
5
.0 Tally brightness fixed16 – 0 1
Sets the tally front and tally
rear brightness to the
same level.
0.0=minimum,
1.0=maximum
.1 Front tally brightness fixed16 – 0 1
Sets the tally front
brightness.
0.0=minimum,
1.0=maximum
.2 Rear tally brightness fixed16 – 0 1
Sets the tally rear
brightness.
0.0=minimum,
1.0=maximum
Tally rear brightness
cannot be turned off
Reference
6
.0 Source int8 enum – 0 2
0=internal,
1=program,
2=external
.1 Offset int32 – – – +/- offset in pixels
Confi-
guration
7
.0 Real Time Clock int32
[0] time _ _ BCD - HHMMSSFF (UCT)
[1] date _ _ BCD - YYYYMMDD
.1 System language string _ _ _
ISO-639-1 two character
language code
.2 Timezone int32 _ _ _ Minutes offset from UTC
.3 Location int64
[0] latitude _ _
BCD -
s0DDdddddddddddd
where s is the sign:
0=north (+), 1=south (-); DD
degrees, dddddddddddd
decimal degrees
[1] longitude _ _
BCD -
sDDDdddddddddddd
where s is the sign: 0=west
(-), 1=east (+); DDD degrees,
dddddddddddd
decimal degrees
238238Developer Information
