Blackmagicdesign DeckLink Series User Manual

Previous DeckLink Cards – Product Diagrams
103
DeckLink Plus
The DeckLink Plus card was bundled with the Multibridge SD. DeckLink Plus can be used by itself to
connect directly to SDI equipment. It can also be used in conjunction with Multibridge SD to connect
to analog equipment such as a Betacam SP deck or for monitoring with an analog monitor.
Deck Control RS-422
SPDIF/AES Output
SD-SDI 4:2:2
Output (to deck)
SD-SDI 4:2:2
Input (from deck)
Genlock Input
