Blackmagicdesign DeckLink Series - Decklink HD Pro 4:2:2 PCI-X

Previous DeckLink Cards – Product Diagrams
98
DeckLink HD Pro 4:2:2 PCI-X
2
3
4
5
6
7
8
9
2. Deck Control
3. R-Y/R Monitor Out
4. Y/G Monitor Out
5. B-Y/B Monitor Out
6. Ref In
7. SPDIF/AES Out
8. SPDIF/AES In
9. Wordclock Out
DeckLink HD Pro Breakout Cable
HD/SD-SDI Output (to deck)
HD/SD-SDI Input (from deck)
