Third Party Applications
37
Adobe Premiere Pro CS5
Adobe Premiere Pro
®
is a powerful real-time video and audio non-linear editing application. Full presets for
Premiere Pro are included with the Blackmagic driver software and will be automatically loaded into your
system during the installation process. Premiere Pro must be installed on your system before running the
Desktop Video installer.
Premiere Pro can capture and playback with sequences of different formats within the one project. For
example, DeckLink can capture 1080i59.94, 1080i50 and NTSC video to corresponding sequences within
the one Premiere Pro project.
Setting Up
1. Launch Premiere Pro CS5.
2. Create a
New Project and click on the Scratch Disks tab.
3. Set the desired Location and Name for your project at the bottom of this window.
4. Set the locations for your captured video, captured audio, video previews and audio previews.
5. Click on the
General tab and set the Capture Format to Blackmagic Capture.
6. Click on the Settings button to reveal the Blackmagic Capture Settings for your project. The Video
Standard can be set to
NTSC, PAL, HD720, HD1080 or 2K. The Video Format can be uncompressed
or compressed. Now click
OK.
7. The New Sequence window will appear. Select the desired Blackmagic preset, give the sequence
a name and then click
OK.
Audio
Blackmagic software features support for multiple channels of audio in Premiere Pro CS5 using the
Blackmagic audio plugin. Blackmagic audio hardware is automatically chosen when a new project is created
and the capture format is set to Blackmagic Capture. The choice of audio hardware can also be configured
through
Premiere Pro > Preferences > Audio Hardware. Verify that the Default Device is set to
Blackmagic Audio.
You may also wish to visit
Premiere Pro > Preferences > Audio Output Mapping to select the mix
of the multi-channel audio. Set
Map Output for to Blackmagic Audio.
Adobe Premiere Pro
New Sequence
Audio Output Mapping
