Blackmagicdesign DeckLink Series User Manual

Contents
Previous DeckLink Cards
Installation & Setup
Installing a DeckLink PCIe card in a Power Mac G5 67
Installing a DeckLink PCI or PCI-X card in a
PowerMac G5 with PCI-X slots 69
Lookup Tables (LUTs) in DeckLink HD Extreme 2 71
Connection Diagrams
Betacam SP analog deck 74
SDI digital deck 75
Sony HDCAM SR deck in 4:2:2 (DeckLink HD Extreme 2) 76
Sony HDCAM SR deck in 4:2:2 (DeckLink HD Pro PCIe) 77
Sony HDCAM SR deck in 4:4:4 78
NTSC/PAL monitor 79
Connecting to S-Video DeckLink HD Extreme 2 80
Connecting to S-Video DeckLink HD Extreme 81
YUV component monitor 82
Connecting to an HDTV 83
HDMI Workflow 84
2K Monitoring with HDLink Pro 85
66
Product Diagrams
DeckLink 87
DeckLink Extreme 88
DeckLink Extreme PCIe 89
DeckLink HD 90
DeckLink HD Extreme and Professional Breakout Cable 91
DeckLink HD Extreme and Consumer Breakout Cable 92
DeckLink HD Extreme 2 and Professional Breakout Cable 93
DeckLink HD Extreme 2 and Consumer Breakout Cable 94
DeckLink HD Extreme 3 95
DeckLink HD Extreme 3D 96
DeckLink HD Plus 97
DeckLink HD Pro 4:2:2 PCI-X 98
DeckLink HD Pro 4:4:4 PCI-X 99
DeckLink HD Pro PCIe 100
DeckLink HD Studio 101
DeckLink Optical Fiber 102
DeckLink Plus 103
DeckLink Pro 104
DeckLink SP 105
DeckLink SP PCIe 106
DeckLink Studio 107
Warranty
Warranty Terms and Conditions 109
86
108
73

Blackmagicdesign DeckLink Series Specifications

General

Interface	PCIe
Bit Depth	8-bit, 10-bit, 12-bit (Varies by model)
Chroma Sampling	4:2:2, 4:4:4 (Varies by model)
Category	Video Capture & Playback Card
Video Inputs	SDI, HDMI (varies by model)
Video Outputs	SDI, HDMI (varies by model)
Audio Inputs	Embedded in SDI/HDMI, Analog (varies by model)
Audio Outputs	Embedded in SDI/HDMI, Analog (varies by model)
Supported Resolutions	4K (varies by model)
Operating System Support	macOS, Windows, Linux
