Component Resistance Readings
Probe Ohms Chart
TEMP
PROBE OHMS
(P/N 51516)
0 1000
20 1078
24 1090
30 1115
50 1195
60 1232
80 1310
93 1360
100 1386
120 1460
150 1575
180 1685
200 1758
230 1868
260 1978
PART NAME OHMS
24VDC Power Supply, Across +V & -V (Unwired DC Voltage) 326
24VDC Power Supply, Across L & N (Unwired Line Voltage) 0.6
Control Transformer (Primary) 25
Control Transformer (Secondary) 0.6
Element, (Single element) 24
Element, (At contactor) 32.5
Heating Contactor Coil 6
Water Solenoid Valve 178
Cooling Fan 3.7
Convection Motor Windings Blue to Black 6.2
Connection Motor Windings Brown to Black 6.2
Connection Motor Windings Brown to Blue 6.2
Circuit Breaker Trip Coil 3.7
Vent Solenoid 30
Step Down Transformer (Primary) 2
Step Down Transformer (Secondary) 1
NOTE: Readings may vary some based on meter capability and accuracy.
