BONFIGLIOLI active cube 201 Quick Start Guide

32 09/08
3.3 ACTIVE Cube 201 (4.0 to 9.2 kW) and 401 (5.5 to 15.0 kW)
Mains power connection, X1
X1
ACTIVE Cube 201-18 (4.0 kW)
:
+
-
L1
L2
L3
L1
L2
L3
PE
3ph / 230V AC
3
p
h / 400V AC
X1
+
-
L1
L2
L3
L1
N
PE
1ph / 230V AC
X1
ACTIVE Cube 201-18 (4.0 kW): 1- und 3-phase connection is possible
Motor power connection, X2
X2
Star connection
VW
U
Delta connection
V
W
U
X2
V
W
U
Rb2
Rb1
M
3~
Use the terminals R
b1
and R
b2
to connect a brake resistor.
3.4 ACTIVE Cube 401 (18.5 to 30.0 kW)
Mains power connection, X1
X1
+
-
L1
L2
L3
L1
L2
L3
PE
3ph / 400V AC
X
1
2.5 Nm
22.1 lb-in
Motor power connection, X2
X2
Star connection
VW
U
Delta connection
V
W
U
X2
V
W
U
Rb2
Rb1
M
3~
2.5 Nm
22.1 lb-in
Use the terminals R
b1
and R
b2
to connect a brake resistor.
09/0832
