58 09/08
3.6 ACTIVE Cube 401 (75,0 kW bis 132,0 kW)
Motoranschluss
W
U
M
3~
WU
WU
Sternschaltung Dreieckschaltung
Anschluss Bremswiderstand mit Temperaturschalter
b
T1
ZK+ Rb2
T
2
Rb2
ZK+
Der Anschluss Rb2 für einen Bremswiderstand ist optional.
Netzanschluss
VW
L1
L2
L3
Rb2
ZK+
ZK-
L2 L3
L1
L2
L3
PE
3ph / 400V AC
10 Nm
88.5 lb-i
n
Gewindebolzen M8x20
09/0858
