Technical Data of the control terminals
Digital inputs (X210A.3 … X210B.2): Low signal: DC 0 V … 3 V, High signal: DC 12 V … 30 V,
input resistance: 2,3 kΩ, response time: 2 ms (STOA and STOB: 10 ms), PLC-compatible
Digital output (X210B.3): Low signal: DC 0 V… 3 V, High signal: DC 12 V … 30 V,
maximum output current: 50 mA, PLC-compatible
Multi-function output (X210B.4):
Analog signal: DC 19 V… 28 V, maximum output current: 50 mA, pulse width modulated (f
PWM
= 116 Hz),
Digital signal: Low signal: DC 0 V… 3 V, High signal: DC 12 V … 30 V, maximum output current: 50 mA,
PLC-compatible,
Frequency signal: output voltage: DC 0 V … 24 V, maximum output current: 40 mA,
Maximum output frequency: 150 kHz
Multi-function input (X210B.6):
Analog signal: input voltage: DC 0 V … 10 V (R
i
=70 kΩ), input current: DC 0 mA … 20 mA (R
i
=500 Ω),
Digital signal: Low signal: DC 0 V… 3 V, High signal: DC 12 V … 30 V, response time: 4 ms, PLC-compatible
Conductor cross section:
Suitable conductor cross sections for the control terminals are:
With wire end ferrule: 0.25…1.0 mm²
Without wire end ferrule: 0.14…1.5 mm²
3.7.1 External 24 VDC voltage supply
The bidirectional control terminals X210A.1/X210A.2 can be used as voltage output or voltage input. If an exter-
nal 24 VDC voltage supply is connected to the terminals X210A.1/X210A.2 the parameterisation and communica-
tion is possible and input and outputs are active, even if the mains voltage is switched off.
The specification of technical requirements of the external voltage supply can be found in the operating instruc-
tions manual.
Requirements of the external voltage supply
Input voltage range 24 VDC ±10%
Input rated current Max. 1.1 A
Inrush current peak Typical: < 25 A
External fuse protection Via commercial available circuit breakers for rated current, charakteristic: slow-
acting
Safety Extra safety low voltage (SELV) according to EN 61800-5-1
09/0836
