BONFIGLIOLI active cube 201 Quick Start Guide

34 09/08
3.6 ACTIVE Cube 401 (75.0 kW to 132.0 kW)
Motor power connection
W
U
M
3~
WU
WU
Star connection Delta connection
Connection of a brake resistor with temperature switch
b
T1
ZK+ Rb2
T
2
Rb2
ZK+
Mains power connection
VW
L1
L2
L3
Rb2
ZK+
ZK-
L2 L3
L1
L2
L3
PE
3ph / 400V AC
10 Nm
88.5 lb-i
n
Threaded bolt M8x20
Note: Optional, the inverters in this size can be purchased without brake chopper and are then not provided with
the terminal Rb2 for a brake resistor connection.
