82 09/08
3.6 ACTIVE Cube 401 (de 75,0 kW à 132,0 kW)
Connexion du moteur
W
U
M
3~
WU
WU
Branchement
en étoile
Branchemen
t
en triangle
Branchement de la résistance de freinage
b
T1
ZK+ Rb2
T
2
Rb2
ZK+
Le branchement Rb2 pour une résistance de freinage est
en option.
Connexion de réseau
VW
L1
L2
L3
Rb2
ZK+
ZK-
L1
L2 L3
L1
L2
L3
PE
3 ph / 400 V AC
Tourillons filetés M8x20
10 Nm
88,5 lb-in
09/0882
