Bosch Access Modular Controller 2 User Manual

Access Modular Controller 2 Installing | en 15
Bosch Security Systems B.V.
Guide d'installation
2022-11 | V04 |
4.3 Opening the case
i
Notice!
To open the controller, first remove all pluggable connectors.
The controller’s case consists of a top cover mounted with a two-point snap-in closure on a
chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the
cover down.
Figure4.3: Opening the controller´s case

Bosch Access Modular Controller 2 Specifications

General

Brand	Bosch
Model	Access Modular Controller 2
Category	Controller
Language	English
