Bosch Access Modular Controller 2 User Manual

44 en | Technical specifications Access Modular Controller 2
2022-11 | V04 |
Guide d'installation
Bosch Security Systems B.V.
10 Technical specifications
Mechanical
Mounting type DIN-rail
Material Housing: ABS and Polycarbonate (UL94V-0)
Dimension (H x W x D) (mm) 90 mm x 232 mm x 63 mm
Dimension (H x W x D) (in) 3.54 in x 9.13 in x 2.48 in
Weight (g) 530 g
Color White
System specifications
Memory – Serial EEPROM
– Pluggable 2 GB compact flash
Reader interfaces – 4x RS485
– Transfer rate: 9.6kbps
– Power voltage depends on input voltage.
Host interface – Ethernet 10/100 Mbit/s
– RS485 / 38.4kbps
– AES128 encrypted
Extension interface RS485 / 9.6kbps
Outputs – 8 relay outputs
– Switching voltage: 30VDC maximum
– Switching current: 1.25A maximum @
30VDC
– Operation modes: wet and dry
Inputs 8 analog inputs with tamper detection
Power consumption 5VA
Tamper 2-wire input for external tamper contact
Reset button Yes
Power – 10VDC to 30VDC
– 60VA maximum
– 55VA (available for external devices)
Display LCD
Environmental
IP rating IP30
Operating temperature (°C) 0 °C – 50 °C
Operating temperature (°F) 32 °F – 122 °F
RoHS Compliant
