11.2.3 Firrmware xx.61, 37.71
Push Display (Example) Description
0 AMC-xxxxx Display firmware variants:
- Bootloader
- WIEGAND
- LBUS
- OSDP
- BG900
1 Vxx.xx xx.xx.xx aa = Reader Protocol Version
37 - Wiegand, 60 - Lbus, 61 - BG900, 62 - OSDP
bb = Firmware Version
01.05.17 release date of the firmware (dd.mm.yy)
2 S/N1: 0910024419 Serial number 18 digits - Part1 10 digits
3 S/N2: 22850034 Part 2 - 8 digits
4 11.18 12:24:18 S Current date and time (MM.DD hh:mm:ss)
(S) = daylight saving
5 Dig. IO: ::::::::::::::::
(only available with
Display of the digital contacts: the input signals
set will be shown with an extension above - output
signals with an extension below. The first eight
digits display the controller’s signals. The second
eight digits display the extension board’s signals
(Not available for Bootloader FW)
5a Dig. I1: ::::::::::::::::
If there are I/O-Boards connected the signals will
be shown on separate pages. (Not available for
Bootloader FW)
5b Dig. I2: ::::::::::::::::
5c Dig. I3: ::::::::::::::::
6 MAC 001B860012AB Network device address (MAC)
7 N AMC-1234-5678 Network name of the controller (max. 14 char.)
See Configuring Ethernet interface, page 34 .
8 I 192.168.10.18 IP-address of the controller
9 G 192.168.10.255 IP-address of the gateway
10 M 255.255.255.0 Subnetmask
11 H 192.168.10.10 IP-address of the host computer
12 DHCP 1 DHCP-status:
1 = on
0 = off
13 D 192.168.10.1 IP-address of the DNS server
14 Host: + "C" Host activity:
+ = online
- = offline
"C" = Counter (0 to 9) of the received data
