Access Modular Controller 2 Appendices | en 51
Bosch Security Systems B.V.
Guide d'installation
2022-11 | V04 |
packages from the host interface.
RS 485 Bus connection:
A = Address 1 … H = Address 8
15 HSC state: x Host secure status:
1 = enable
2 = disable
(Not available for Bootloader FW)
11.2.4 Firmware xx.62, 37.72
This firmware supports DTLS. For details on how to set the required device communication
password, refer to the configuration manual of the host system.
– If a brand-new AMC is connected to a host system supporting DTLS, the AMC will be
configured with DHCP active and its IP address will be set to a device-specific link-local IP
address in the range 169.254.0.0/16.
– If the network is operating with a DHCP server, the AMC will get its network configuration
automatically from the DHCP server.
– If the network is operating without a DHCP server, the link-local address will remain
active until otherwise configured via the AMCIPConfig tool.
Push Display (Example) Description
0 AMC-xxxxx Display firmware variants:
- Bootloader
- WIEGAND
- LBUS
- OSDP
- BG900
1 Vxx.xx xx.xx.xx aa = Reader Protocol Version
37 - Wiegand, 60 - Lbus, 61 - BG900, 62 - OSDP
bb = Firmware Version
01.05.17 release date of the firmware (dd.mm.yy)
2 S/N1: 0910024419 Serial number 18 digits - Part1 10 digits
3 S/N2: 22850034 Part 2 - 8 digits
4 11.18 12:24:18 S Current date and time (MM.DD hh:mm:ss)
(S) = daylight saving
5 Dig. IO: ::::::::::::::::
(only available with
Display of the digital contacts: the input signals set will
be shown with an extension above - output signals with
an extension below. The first eight digits display the
controller’s signals. The second eight digits display the
extension board’s signals.
(Not available for Bootloader FW)
5a Dig. I1: ::::::::::::::::
If there are I/O-Boards connected, the signals will be
shown on separate pages. (Not available for Bootloader
FW)
5b Dig. I2: ::::::::::::::::
5c Dig. I3: ::::::::::::::::
6 MAC 001B860012AB Network device address (MAC)
